Robust and durable design adapted for all agricultural operations. Designed to handle gravel, silage, sawdust, dirt, peat moss and snow.
Cotech gravel buckets are made from premium-grade steel and robotically welded. Like all Cotech products, the buckets are powder-coated to enhance corrosion resistance. Their conical shape makes loading and unloading material easier.
The 6" x 3/4" cutting edge and 3/8" thick side reinforcements deliver superior performance. The curved double bottom is reinforced underneath with 3/8" x 3" steel supports. Wear parts are made from Hardox® 450, reducing weight while increasing durability.
Multiple dimensions are available to suit your operational needs.
45-115 HP
| Models | Capacity | Width | Height | Depth | Weight |
|---|---|---|---|---|---|
BG-54 | 0.63 yd3 | 54" | 29.5" | 30.5" | 430 lbs |
BG-60 | 0.70 yd3 | 60" | 29.5" | 30.5" | 460 lbs |
BG-66 | 0.78 yd3 | 66" | 29.5" | 30.5" | 485 lbs |
BG-72 | 0.85 yd3 | 72" | 29.5" | 30.5" | 514 lbs |
BG-84 | 1 yd3 | 84" | 29.5" | 30.5" | 581 lbs |
BG-90 | 1.07 yd3 | 90" | 29.5" | 30.5" | 613 lbs |
BG-96 | 1.13 yd3 | 96" | 29.5" | 30.5" | 645 lbs |
